Copper Rod
Product Applications: Resistance welding electrodes, welding equipment
Product Performance:
| Material | Dimensions | Tensile Strength （min) | Yield Strength （min) | Elongation （min) | Electrical Conductivity （min) | Hardness （min) |
| C18150 | φ5-φ50 | 470MPa | 400MPa | 15% | 80%IACS | 80HRB |
| C18150 | ≥φ51 | 400MPa | 300MPa | 15% | 80%IACS | 67HRB |
| C18200 | φ5-φ50 | 400MPa | 300MPa | 15% | 80%IACS | 67HRB |
| C18000 | φ5-φ50 | 630MPa | 550MPa | 9% | 45%IACS | 90HRB |
| C18000 | ≥φ51 | 6200MPa | 520MPa | 9% | 45%IACS | 90HRB |
| C15000 | φ5-φ50 | 380MPa | 300MPa | 13% | 85%IACS | 60HRB |
Copper Plate
Product Applications: Continuous casting molds, machining
Product Performance:
| Material | Dimensions | Tensile Strength （min) | Yield Strength （min) | Elongation （min) | Electrical Conductivity（min) | Hardness （min) |
| C18150 | T>20, W<1500, L<6000 | 400MPa | 280MPa | 15% | 80MS/m | 110HB |
| C18000 | T>20, W<900, L<6000 | 500MPa | 380MPa | 10% | 45MS/m | 180HB |
| C17510 | T>20, W<900, L<6000 | 630MPa | 510MPa | 14% | 60MS/m | 200HB |
| CuAg0.1 | T>20, W<900, L<6000 | 265MPa | 260MPa | 16% | 95MS/m | 90HB |
| CuCo1Ni1Be | T>20, W<900, L<6000 | 650MPa | 500MPa | 8% | 43MS/m | 235HB |
| CuAl10Ni5Fe4 | T>20, W<900, L<6000 | 650MPa | 350MPa | 12% | / | 175HB |
